6 Inch Stainless Steel Fountain Pumps

HUALUO 6SP series is designed for deep-well extraction and professional water features. Produced in a 13,680 m² facility by a team of 130+, each 6-inch pump delivers wire-to-water efficiency to reduce operating costs.

Model-by-Model Breakdown

ModelMax Flow (m³/h)Max Head (m)Power/Stage (P2​)Best Efficiency Point (BEP)
6SP60 (150QJ60)75.02801.6 – 2.1 kW60 m³/h
6SP46 (150QJ46)60.02951.0 – 1.6 kW46 m³/h
6SP30 (150QJ30)40.04450.65 – 1.0 kW30 m³/h
6SP17 (150QJ17)25.04750.38 – 0.55 kW17 m³/h
As flow increases from 6SP17 to 6SP60, the Best Efficiency Point (BEP) shifts to higher flow rates, matching large-scale agricultural needs. The 6SP17 reaches a maximum head of 475 m, but its peak efficiency occurs at lower flow. The 6SP60 maintains high efficiency at high flow, making it suitable for continuous irrigation.

Core Specs

Flow Range: 2 – 75 m³/h
Head Range: Up to 475 m
Power Range: 0.38 kW – 2.1 kW

Technical Highlights

Stainless steel construction – Withstands high static head pressures.
NEMA standard coupling – Compatible with international 6-inch submersible motors.
Water-lubricated bearings – Designed for continuous operation in harsh environments.

Primary Applications

Large-Scale Municipal Water Supply
Industrial Cooling & Process Water
High-Flow Musical Fountain Projects
Agricultural Water Distribution
